AiM GS Dash Display for EVO4S & EVO5

AiM GS Dash Display for EVO4S and EVO5

The AiM GS Dash is a compact display designed to show data sampled by compatible AiM EVO4S or EVO5 data loggers. It can present vehicle ECU data, GPS information, sensor channels, and inertial-platform data in a clear, configurable dashboard.

This is not a standalone logger. The GS Dash must be connected to a compatible EVO4S or EVO5 system. Confirm the logger, harness, channels, and installation requirements before ordering.

Clear data from your AiM EVO system

• 268 × 128 pixel display designed for readable motorsport data presentation.
• Seven selectable backlight colours for the display.
• Ambient light sensor to help maintain useful brightness and contrast in changing conditions.
• Configurable pages showing lap times and selected channels, with up to eight fields per page.
• RPM and lap-time layout for RPM graph, lap time, and selected channels.
• Five configurable RGB shift lights with selectable colours and activation thresholds.
• Shift-light functions that can also display best lap or split information, or monitor RPM where configured.

AiM data workflow reference.

Compatibility and installation

The GS Dash can only be used with and connected to compatible AiM EVO4S or EVO5 systems. The data shown depends on the logger configuration, vehicle ECU, connected sensors, GPS, harness, and available channels.

For the correct wiring and setup, plan the GS Dash as part of the complete AiM system rather than as a replacement for the EVO logger. Contact Harris Race Radios before ordering if you need help checking compatibility.

Race Studio 3 setup reference from AiM's official documentation.

Race Studio 3 workflow

Race Studio 3 supports the configuration workflow for compatible AiM systems, including display pages, channels, alarms, shift lights, track information, data downloads, and analysis where the connected EVO logger supports those functions.

Official AiM and Race Studio videos

These official AiM videos support the wider configuration, data-transfer, firmware, and Race Studio 3 workflow used with compatible AiM systems. For the complete official library, visit the AiM Academy Training Videos page.

GS Dash support

Use the AiM Race Studio 3 Knowledge Hub for configuration, data-transfer, firmware, and troubleshooting workflows. Visit AiM Downloads & Documentation for official live AiM software, firmware, and product-documentation sources.

For EVO4S or EVO5 compatibility, harness selection, ECU and sensor planning, or installation advice in New Zealand and Australia, contact Harris Race Radios.
